Tænk på FS1-X som alle AJAs fine mini convertere bygget sammen - og på coke trip.... tilføj så motion adaptive frame rate konvertering og MADI support... Så har du den ultimative 1U konverter der tilmed er til at betale!
AJA FS1-X er den ultimative schweitzerkniv når det kommer til at håndtere en lang række forskellige audio og video formater og fixe en lang række syncproblemer med video og audio.
Med tilføjelsen af FS1-X Frame Rate Converteren i "FS1-X with FRC" versionen, får man et meget kærkomment værktøj til at håndtere konvertering fra feks. 24 til 25fps, uden at få stutter eller jerky motion, som på godt dansk kan tilskrives de "high quality motion adaptive linear frame rate conversion" algoritmer, FS1-X - FRC er udstyret med. Oveni er der support for 64 kanals MADI audio over ét coaxial eller fiberkabel. En 224x224 audio router matrix, giver fuld kontrol med de mange forskellige audio input signaler.
Embed eller deembed lyd inklusiv delay compensation for hver kanal, genlock, up/down/cross konvertering, alle in og output typer og flere samtidige konverteringer, support for Closed Captions, proc amp og meget mere, - gør FS1-X til et rigtigt godt værktøj i OB vognen, CART rummet, live riggen, til AV brug og alle mulige andre applikationer.
Som framesync, kan FS1-X foran f.eks en ingest kanal, sikre at udfald i billede og lyd ikke vil påvirke synkroniseringen imellem lyd og billede.
FS1-X har alle in og outputs: 2x SDI, Composite, Component og YC, og laver alle former for up/down/cross konverteringer, audio embed / deembed o.s.v.
Betjeningen enkel og meget overskuelig via web interface, og netværksporten tillader såmænd også fuld overvågning via SNMP ( Simple Network Management Protocol ).
Digital Video input:
Dual 3G-SDI, SMPTE-259/292/296, 8- or 10-bits
3G SDI Dual Link, Dual Stream, Level A or B
Dual Fiber (SC or LC) SD/HD/3G SDI, SMPTE-259/292/296, 8- or 10-bits (optional)
HDMI 30 bits/pixel, RGB or YUV, SD, HD, 1080p-50/60
Analog Video input:
SD/HD component YPbPr, SMPTE-274 (3 x BNC)
12-bit A/D, 2x oversampling
+/- .25 dB to 5.5 MHz Y Frequency Response
+/- .25 dB to 2.5 MHz C Frequency Response
.5% 2T Pulse Response
<2 ns Y/C delay inequity
SD Composite
12-bit A/D, 4x oversampling
Digital video output:
Dual 3G-SDI, SMPTE-259/292/296, 8- or 10-bits
3G SDI Dual Link, Dual Stream, Level A or B
Dual Fiber (SC or LC) SD/HD/3G SDI, SMPTE-259/292/296, 8- or 10-bits (optional)
HDMI 30 bits/pixel, RGB or YUV, SD, HD, 1080p-50/60 Video Output Analog
Analog video output:
SD/HD component YPbPr, SMPTE-274 (3 x BNC)
12-bit A/D, 2x oversampling
+/- .25 dB to 5.5 MHz Y Frequency Response
+/- .25 dB to 2.5 MHz C Frequency Response
.5% 2T Pulse Response
<2 ns Y/C delay inequity
SD Composite
12-bit A/D, 4x oversampling
Digtal Audio Input:
64-channel MADI, Coax or Fiber, 48kHz sample rate, Synchronous
16-channel, 24-bit SDI embedded audio, 48kHz sample rate, Synchronous
16-channel, 24-bit AES/EBU audio, 48kHz sample rate, Synchronous or Non-synchronous, Internal sample rate conversion (4 x BNC)
Analog audio input:
8-channel, 24-bit A/D analog audio, 48kHz sample rate, balanced (25 pin "D" TASCAM connector)
Digital Audio output:
64-channel MADI, Coax or Fiber, 48kHz sample rate, Synchronous
16-channel, 24-bit SDI embedded audio, 48kHz sample rate, Synchronous
16-channel, 24-bit AES/EBU audio, 48kHz sample rate, Synchronous or Non-synchronous, Internal sample rate conversion (4 x BNC)
Analog Audio Output:
8-channel, 24-bit D/A analog audio, 48kHz sample rate, balanced (25 pin "D" TASCAM connector)
Up Conversion:
Hardware 10-bit
Anamorphic: full-screen
Pillar box 4:3: results in a 4:3 image in center of screen with black sidebars
Zoom 14:9: results in a 4:3 image zoomed slightly to fill a 14:9 image with black side bars
Zoom Letterbox: results in image zoomed to fill full screen
Zoom Wide: results in a combination of zoom and horizontal stretch to fill a 16:9 screen; this setting can introduce a small aspect ratio change
Down Conversion:
Hardware 10-bit
Anamorphic: full-screen
Letterbox: image is reduced with black top and bottom added to image area with the aspect ratio preserved
Crop: image is cropped to fit new screen size
Cross conversion:
Hardware 10-bit
1080i to 720P
720P to 1080i
1080P to 720P, 720P to 1080P
For at runde hele denne overbevisende cocktail af, så giver AJA 5 års "return to factory" garanti
Se også storebror FS2 der tilbyder to kanaler i en rackunit, og yderligere mulighed for dolby E decodning med option.Dokument(er)
Hent de fulde specs - Whitepaper her
